Login- SKU: TB3D2D24K-H
- Barcode (EAN):
- Warranty: 2 Years
- Physical Characteristics: Colour: Black | Dimensions: 230(L) X 87.3(W) X 27(H) mm
- Data Rate: 40Gbps
- Compliance: ThunderboltTM 3
- Resolution: Single display - ThunderboltTM 3: 3840x2160@60Hz, HDMI: 3840x2160@60Hz | Multiple display - ThunderboltTM 3: 3840x2160@60Hz, HDMI: 3840x2160@60Hz
- Input: ThunderboltTM 3 × 1
- Output: USB-A (USB 3.0) × 5, ThunderboltTM 3 × 1, HDMI x 1, Gigabit Ethernet x 1, Audio+Voice x 1, SD Card Reader x 1
- Compatibility: ThunderboltTM 3 Port on Windows 10 & above or Mac OS Sierra & above computer
Thunderbolt 3.0 Dock Introduction
The Alogic TB3D2D24K-H is a Dual 4K Display Thunderbolt 3.0 dock with power delivery which works with both Mac & Windows computers. The dock supports all the miracles of Thunderbolt 3.0 such as native support for 40Gbps data transfer speed, 4K video and power delivery with a single cable.
Thunderbolt 3.0: One cable for Power, Video & Data
The dock connects to your Thunderbolt 3.0 enabled laptop by just one single Thunderbolt cable to charge your laptop, transfer data (up to 40Gbps), connect dual monitors, Gigabit Ethernet and an audio device at the same time. Supports PD (Power Delivery) and can charge your laptop with up to 60W of power through the Thunderbolt 3.0 connection. Laptops rated 80W or 85W will also charge through the dock at a slower speed.
Dual 4K Display Output: Increased Productivity
The versatile dock allows you to connect two monitors simultaneously through the (1) HDMI and (1) Thunderbolt 3.0 outputs on the dock to EXTEND OR MIRROR the content. The maximum resolution supported with dual display is 3840 x 2160@60Hz from both ports. The Thunderbolt 3.0 port is Compatible with USB-C video adapters and cables such as DisplayPort, HDMI, VGA, etc.
Gigabit Ethernet & USB Expansion
The dock also features a gigabit ethernet port to enable connection to a wired network. The dock has 5 USB 3.0 for connecting all your accessories such as mouse, keyboard, hard drive, printers etc. The dock also has Thunderbolt 3.0 port which can be used for Video/Audio output or Connection a Thunderbolt Accessory. The 3.5mm audio jacks lets you connect headphone & mic with ease.
